Manual Powder Characteristics Tester
PowderPro M1 is used to measure the physical properties of a powder pile. The basic physical characteristics of powdered materials are practically significant in powder production, processing, transportation, storage and other applications. For example, angle of repose and angle of fall should be considered while designing cone angle silos; tapped and bulk densities should be taken into account while designing packaging bags and barrels or during the production of tablets made from powdered raw materials,etc.
Model :
A1
Features and Benefits
•Measured parameters:
Angle of Repose, Angle of Fall, Angle of Spatula, Angle of Slide, Voidage, Cohesion, Bulk Density, Tapped Density, Dispersibility, and Hall Flow Rate (customized).
•Calculated parameters:
Angle of Difference, Uniformity, Compressibility, Flowability Index, and Floodability Index.
•Compliance:
Testing methods are fully compliant per ASTMD6393-14, USP32-NF27<616>, and European Pharmacopoeia EP7.0 07/2010: 20934, GB/T16913-2008-4.5, GB/ T1479.1-2011, and GB/T5162-2006.
•Measured parameters:
Angle of Repose, Angle of Fall, Angle of Spatula, Angle of Slide, Voidage, Cohesion, Bulk Density, Tapped Density, Dispersibility, and Hall Flow Rate (customized).
•Calculated parameters:
Angle of Difference, Uniformity, Compressibility, Flowability Index, and Floodability Index.
•Compliance:
Testing methods are fully compliant per ASTMD6393-14, USP32-NF27<616>, and European Pharmacopoeia EP7.0 07/2010: 20934, GB/T16913-2008-4.5, GB/ T1479.1-2011, and GB/T5162-2006.
•Angle of Repose
•Bulk Density and Tapped Density
| Testing items | Total 15 items: angle of repose, angle of fall, angle of difference, angle of spatula, angle of slide, voidage, uniformity, cohesiveness, bulk density, tapped density, compressibility, dispersibility, flowability index, floodability index, Hall flow rate. |
| Angle range | 0-90° |
| Angle testing method | Protractor. Testing the repose angle, collapse angle and plate angle by the protractor. |
| Repeatability error | ≤5% |
| Tap density frequency | 250 times/min |
| Tap density amplitude | 3mm or 14mm |
| Standard | China standard :GB/T16913-2008 4.5;GB/T1479.1-2011; GB/T5162-2006 |
| United States Standard : ASTM D6393-14 | |
| United States Pharmacopeia : USP32-NF27<616> | |
| European Pharmacopoeia ：EP7.0 07/2010：20934 | |
| Power supply | AC 220V, 50/60Hz, 200W |
| Volume & weight | 580x350x650mm、37kg |
PowderPro M1 is used to measure the physical properties of a powder pile. The basic physical characteristics of powdered materials are practically significant in powder production, processing, transportation, storage and other applications. For example, angle of repose and angle of fall should be considered while designing cone angle silos; tapped and bulk densities should be taken into account while designing packaging bags and barrels or during the production of tablets made from powdered raw materials,etc.
